Dunlop Echoplex Preamp Pedal

The Echoplex Preamp recreates the EP-3's legendary preamp mojo, following the same signal path with FET circuitry and a Gain control for up to +11dB boost.

This pedal can be powered by a 9-volt battery, a Dunlop ECB003 9-volt adapter, or the DC Brick, Iso-Brick, and Mini Iso-Brick power supplies (not included).

Specs

• Input Impedance: 730 kΩ
• Output Impedance: 55 kΩ
• Max Input Level: -5 dBV
• Max Output Level: +5.5 dBV
• Noise Floor: -95 dBV
• Max Gain: +11 dBV
• Bypass: True Hardwire
• Current Draw: 12 mA
• Power Supply: 9 volts DC
